Page 17SKU 96698 For technical questions, please call 1-800-444-3353.
HEX
HEAD BOLT
SPINDLE
WASHER
FLANGE
7. Remove the hex head bolt, spindle
Reinstall a new Blade on the Arbor. 8.
Match the direction arrows on the
new blade with the direction arrow on
the saw Blade Housing.
9.
Tighten securely.
Rotate the Center Cover back into 10.
place and tighten the Bolt.
Adjusting the Fence
The Fence holds the work piece in a 1.
the blade assembly are adjusted in a
miter or bevel angle.
To make accurate cuts, the Fence 2.
must be perpendicular (at a 90º
angle) to the Saw Blade.
Before beginning work, make a test 3.
cut on scrap material with the Table
set at 90º.
Check the cut with an accurate 4.
pieces, hold the cut ends together,
and hold a good straight edge along
the side of the pieces.
If either test reveals that the cut is not 5.
a true 90º angle, you must adjust the
Fence before beginning work.
6.
tool.
7.
8.
the table with one edge along the
blade and the other along the Fence.
Any inaccuracy should be visible.
surface of the blade, not the teeth, for
an accurate reading.
The Fence is held in place with 9.
slightly, and gently tap the Fence into
position using a soft mallet. Retighten
the bolts and make another test cut.
Repeat the process until the Fence is
adjusted accurately.
Once the Fence is accurately 10.
place. Recheck one last time, then
proceed to work.
Adjusting the Miter Table
Indicator
After you have checked or adjusted 1.
the fence to be sure it is at 90º to the
Blade, you must check the accuracy
of the Miter Table Angle Indicator.
