Chapter 2 Installation
Installing Your Router
2-6
Cisco 828 Router and SOHO 78 Router Hardware Installation Guide
78-12837-02
Hub without equivalent to
router TO HUB/TO PC
button
ETHERNET port 4 Straight-through OUT MDI-X
(OUT)
Server, PC, or workstation ETHERNET port 4 Straight-through OUT –
Hub with equivalent to
router TO HUB/TO PC
button
ETHERNET port 1, 2,
3
Crossover N/A MDI (IN)
Hub with equivalent to
router TO HUB/TO PC
button
ETHERNET port 1, 2,
3
Straight-through N/A MDI-X
(OUT)
Hub without equivalent to
router TO HUB/TO PC
button
ETHERNET port 1, 2,
3
Crossover N/A MDI-X
(OUT)
Server, PC, or workstation ETHERNET port 1, 2,
3
Straight-through N/A –
1. Cisco provides a yellow straight-through cable. You provide crossover or additional straight-through cables. For cable
specifications, see Appendix A.
2. Hub vendors choose different names for the button controlling cable selections. For this table, the
Cisco 1528 Micro Hub 10/100 with an MDI/MDI-X button is assumed. Determine the button name and setting for your
particular hub. See your hub documentation for details.
Table 2-2 Ethernet Device Connections (continued)
Network Device
Connected to Router Router Port
Ethernet Cable
Type
1
Router TO
HUB/TO PC
Button Setting
Network
Device
Button
Setting
2
