Cisco Aironet Four-Element, MIMO, Dual-Band Ceiling Mount Omnidirectional Antenna (AIR-ANT2524V4C-R)
78-20577-01
Obtaining Documentation, Obtaining Support, and Security Guidelines
Note Do not use the rubber gasket when you mount the antenna on a ceiling tile. The gasket is not
required for ceiling tile installations.
Step 6 Make sure that the antenna is properly positioned on the ceiling tile and then tighten the plastic nut
hand-tight.
Step 7 Reinstall the ceiling tile.
Step 8 Connect the antenna cables to the access point.
Note The 5-GHz antenna cables are identified by a orange collar near the connectors. Make sure that
you connect these cables to the 5-GHz antenna connection on the access point.
Suggested Cable
Cisco recommends a high-quality, low-loss cable for use with the antenna.
Note Coaxial cable loses efficiency as the frequency increases, resulting in signal loss. The cable
should be kept as short as possible because cable length also determines the amount of
signal loss (the longer the run, the greater the loss).
Obtaining Documentation, Obtaining Support, and Security
Guidelines
For information on obtaining documentation, obtaining support, providing documentation feedback,
security guidelines, and also recommended aliases and general Cisco documents, see the monthly
What’s New in Cisco Product Documentation, which also lists all new and revised Cisco technical
documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
