FEIN Power Tools FMM 250Q Sander User Manual



20
 Sanding
 General accessories
 Polishing
 Cutting
 Extraction
 Sanding
 General accessories
Sanding fi nger
With H&L on top and under-
side. Pack of 2.
Height Order number
¹/₁₆" 6 38 06 158 02 9
Sanding sheets for sanding
ngers
With H&L, fully bonded with
artifi cial resin, high sanding
capacity, corundum. Application:
wood, metal, soldered joints, fi berglass-
reinforced plastic, plastic, paint, fi ller,
leather, pack of 20.
Grit Order number
40 6 37 17 184 01 2
60 6 37 17 185 01 6
Sanding sheets-dust
extraction
For sanding with dust
extraction. For universal
application on practically all surfaces.
Corundum sanding grains, fully bonded
with artifi cial resins guarantee high san-
ding capacity. From grit 36 to 280 grit.
Sanding sheet set
10 of each type of sanding
sheet, perforated for dust
extraction, with H&L
corundum, grit 60, 80,
120, 180, 240 grit.
Order number
6 37 17 109 03 5
Grit Pack of 5 Pack of 50
Order no. Order no.
6 37 17 ... 6 37 17 ...
36 ... 107 04 9 ... 107 01 1
40 ... 108 04 7 ... 108 01 9
60 ... 109 04 1 ... 109 01 3
80 ... 110 04 3 ... 110 01 5
100 ... 111 04 2 ... 111 01 4
120 ... 112 04 5 ... 112 01 7
150 ... 113 04 9 ... 113 01 1
180 ... 114 04 7 ... 114 01 9
Grit Order number
80 6 37 17 186 01 9
100 6 37 17 187 01 3
120 6 37 17 188 01 1
150 6 37 17 189 01 5
180 6 37 17 190 01 7
220 6 37 17 191 01 6
240 6 37 17 192 01 9
280 6 37 17 193 01 3
320 6 37 17 194 01 1
400 6 37 17 195 01 5
Segment blade, convex
For cutting rigid materials
such as plastic, linoleum,
rubber, cardboard, leather,
woven wire cloth, looped fabric/carpet
fl oor coverings, and much more.
Order number
6 39 03 205 01 5
Cutter blade
For cutting out panelled deck
sealant materials. Also for
problem areas such as cabins,
rails, gunwales, cleats and curves.
Blade width Order number
¹/₈" 6 39 03 200 01 7
⁵/₃₂" 6 39 03 201 01 6
³/₁₆" 6 39 03 202 01 9
Set of sanding
pads-dust extraction
For sanding with dust
extraction, pack of 2.
Order number
6 38 06 136 02 9
Grit Pack of 5 Pack of 50
Order no. Order no.
6 37 17 ... 6 37 17 ...
220 ... 115 04 1 ... 115 01 3
240 ... 116 04 4 ... 116 01 6
280 ... 117 04 8 ... 117 01 0
Adapter hose
For connecting the dust extractor to
vacuum cleaners. Suction hose attach-
ment Ø 1 ¹/₁₆".
Model Order number
Thin 3 06 05 110 00 8
Thick 3 06 05 109 00 6
Set of felt polishing
pads
For polishing metal parts,
as well as for polishing and
decorative polishing of stone and stone
products. Gelcoat layers on boats can
also be polished. Pack of 2.
Order number
6 38 06 140 02 7
FEIN T
URBO I
The addition for dust-free work, wet
or dry. With a socket on the device,
automatic on/off, 5 casters for unlimited
freedom of movement.
Order number
9 11 55
Included in the set:
1 Suction hose, 16 ft, Ø 1 ¼";
1 Crevice tool;
1 Adaptor;
1 Brush;
1 5 Micron cloth bag
Filter bags for FEIN Turbo I
Pack of 3
Order number
913038K01
Carrying case, fi lled
The plastic case with T
OP equipment for your SELECT
pack. 1 sanding pad, perforated for dust extraction;
5 of each perforated sanding sheets, grit 60, 80, and 120;
180. 1 dust extractor, 2 hose nozzles hose connection
Ø 1
¹/₁₆
", 1
¹/₄
" and 2 adaptors for common domestic
vacuum cleaners, profi le sanding set, 1 carbide rasp.
Order number
3 39 01 118 17 0
Carrying case, unfi lled
Plastic carrying case with practical
inner spacing, without machine and
accessories. Optimally suited for storing
FEIN M
ULTIMASTER START and
FEIN M
ULTIMASTER SELECT.
Order number
3 39 01 118 03 0
Table and drill stand support
Perfect for precision cut-outs: the FEIN M
ULTIMASTER can be clamped to a
table or 1 ¾" workbench. It can also be clamped to commercially available
drill stands with a 43 mm collar diameter. Only suitable for the FEIN
M
ULTIMASTER FMM 250/250Q.
Order number
9 26 02 083 01 0
Cutting
Segment blade, concave
For cutting soft materials
such as felt, leather and
polystyrene.
Order number
6 39 03 193 01 8
Dust extractor kit for FMM only:
2 sanding pads, perforated; 5 of each type
of sanding sheet perforated, grit 60, 80
and 120; 1 extractor hood with suction
tube; 2 hose nozzles for hose connec-
tion Ø 1 ¹/₁₆" and 1 ¹/₄" plus 2 adapters
for connection to the most common
domestic vacuum cleaners. For the FEIN
M
ULTIMASTER FMM 250/250Q.
Order number
9 26 02 081 01 0
 Dust extraction
Technical data:
Power consumption 1,000 W
Air fl ow rate 116 cfm
Static water lift 90"
Container volume 6 gal
Weight 17.7 lbs
Cable with plug 16 ft
