E-
50984
DRILLING MOTOR MODEL NO. – 5GEB22
.ON LAIRES
COOLING–3000 SCFM AIR SUPPLIED
BY BLOWER UNIT
RATINGS S9 CONTINUOUS
AMBIENT AIR MAX 45 C 45 C / 55 C
PHASE 3
AC VOLTS (L-L) 587
AMPS AC 1380 1120 / 1048
RATER RPM 800
MAX. FREQUENCY HERTZ 153
SHAFT HP 1400 1150 / 1075
MAX OPERATING RPM 3000
CONSTANT HP 800–1800 RPM (600 VOLT L–LINE SUPPLY)
WITH 600 VOLTS MAINTAINED ABOVE 820 RPM
CONSTANT HP 800–2400 RPM (690 VOLT L–LINE SUPPLY)
WITH 690 VOLTS MAINTAINED ABOVE 940 RPM
INSULATING CLASS H
N WYEOITCENNOC
INGRESS PROTECTION
IP44 / 6424 LBS (2914 Kg)
IP56 / 7124 LBS (3238 Kg)
CLOSED COOLING SYSTEM, IP56, TO MAINTAIN MAX.
INTERNAL AIR TEMPERATURE OF 45 C
GE Proprietary and Confidential Information
