SKU 04041 For Technical Questions, Please Call 1-800-444-3353 Page 2
PRODUCT SPECIFICATIONS
Save This Manual
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet
locations. Do not expose to rain. Keep work area well lit. Do not use electrically
powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not let
them handle machines, tools, extension cords, or air hoses.
4. Store idle equipment. When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.
5. Use the right tool for the job. Do not attempt to force a small tool or attachment to
do the work of a larger industrial tool. There are certain applications for which this
tool was designed. It will do the job better and more safely at the rate for which it was
intended. Do not modify this tool and do not use this tool for a purpose for which it
was not intended.
6. Dress properly. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically non-conductive clothes and non-skid footwear
are recommended when working. Wear restrictive hair covering to contain long hair.
7. Do not overreach. Keep proper footing and balance at all times. Do not reach over
or across running machines or air hoses.
REV 01/04 REV 08/05 REV 01/06 REV 11/06
Nail Size (.113” to .131” Thick), 10 Gauge (Round Head), 2-3/16” to
3-1/2” Long; 21
o
Full Head Nails
Magazine Capacity 60 Nails
Operating PSI 70 to 125 PSI*
Required Air CFM Intake 3 - 3.5 CFM at 90 PSI
Accessories Carrying Case, Safety Goggles, Machine Oil, 180 Nails
Features Single Sequential Safety Trip Mechanism, 360
o
Exhaust
Flow Adjustment, Soft Rubber Grip, 1/4” NPT (18 TPI) Air
Inlet with Screen, Adjustable Depth Drive
Weight 9.9 Lbs.
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with
this manual. Write the invoice number on the inside of the front cover. Keep the manual
and invoice in a safe and dry place for future reference.
* The air pressure setting must not exceed job site regulations/restrictions. The air
pressure setting must not exceed 90 PSI when being used with work pieces that
have a thickness of less than 1-3/4”.
