Page 4 SKU # 42977
#42977 DRILL / MILL MACHINE STAND PARTS DIAGRAM
MAINTENANCE
1. Keep the stand wiped down and clean.
2. Do not allow the stand to remain wet, and do not allow standing water to accumulate around the base.
3. Use applications of light grease or paint to any unpainted surfaces to prevent rust.
4. Check the floor mounting bolts and machine mounting bolts monthly to assure that they remain securely
fastened. Retighten or replace any fastening hardware as needed.
WARNING!
USE THE RIGHT TOOL FOR THE JOB. Do not attempt to force a small tool or attachment to do the work
of a larger industrial tool. There are certain applications for which this tool was designed. Do not modify this tool
and do not use this tool for a purpose for which it was not intended.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A
REFERENCE TOOL ONLY: NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION
OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO
THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT: IN FACT THE
MANUFACTURER A ND/OR DISTRIBUTOR EXPRESSLY STATES THATALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE
BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
P/N DESCRIPTION
1 Body
2 Door
3 Hinge
4 Door Handle Assembly
A B C D E F
DOOR HANDLE
ASSEMBLY
P/N DESCRIPTION
A Bolt
B Spring
C Handle
D Sleeve
E Door Holder
F Spring Washer
G Nut
2
3
1
A
B
C
D
E
F
G
REV 09/06
