Page 5For technical questions, please call 1-800-444-3353.
Item 67854
91214
Unpacking: When unpacking, make sure all the parts are included. Refer to the Parts List and
Assembly Diagram at the end of this manual. If any parts are missing or broken, please
call Harbor Freight Tools at 1-800-444-3353 as soon as possible.
SHADE GUIDE CHART
Welding
Process
Arc Current (Amperes)
10 20 40 80 125 175 250 300 450
5 15 30 60 100 150 225 275 350 500
Stick/Arc 9 10 11 12 13
Mild Steel MIG
(argon shielded)
10 11 12 13
Mild Steel MIG,
(CO
2
shielded)
10 11 12 13
Aluminum MIG 10 11 12 13
TIG 10 11 12 13
Flux Core 10 11 12 13
Plasma Cutting 11 12 13
Plasma Welding 9 10 11 12 13
SPECIFICATIONS
Description Auto-Darkening Welding Helmet
Power Source Solar powered cells with battery assistance (not rechargeable)
Operating Temp. 23° to 131° F
Resting Shade Shade # 4
Shade Range 9 to 13
UV/IR Protection up to DIN 16 at all times
Lens Type ANSI Z87.1-2003 approved
Viewing Area 3.86” x 1.73”
Welding Protection
Types
For Processes including MIG/Flux welding, stick welding, TIG welding (10+
amps), plasma arc welding/cutting and air carbon cutting. Not for Laser Welding or
Oxyacetylene Welding/Cutting
Lens Switching
Speed (Clear to Dark)
1/25,000 second
Sensitivity Adjustment High / Low
Grinding Mode Transforms helmet to grinding shield without shade ickering
Power ON / OFF Fully Automatic
Shell Material High Impact-Resistant Plastic Polyamide Nylon
Storing Temperature -4° to 158° F
Features
Ratcheting headband with replaceable padded sweatband, spare External cover lens,
2 independent arc sensors which reduce the risk of blocked sensors during out-of-
position welding, variable Shade Control Knob adjusts from #9 to #13 with a #4 resting
shade, Delay Control Switch, Sensitivity Control Switch
Weight 1.3 lb.
