SKU 93271 For technical questions, please call 1-800-444-3353. PAGE 2
SPECIFICATIONS
Maximum Air Pressure 115 PSI with Auto Shut-Off
Air Tank Capacity 21 Gallons
Air Flow Capacity 3.5 CFM at 90 PSI
8.8 CFM at 40 PSI
Electrical Requirements 230 V~ / 60 Hz / 7 A / 1 Phase
3 HP rated
Pump Stage Single
Air Outlet Size 1/4” - 18 NPT
Shipping Weight 152 Pounds
Power Cord 10’ - Electrical Plug Sold Separately
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and assembly
diagram. Keep your invoice with this manual. Write the invoice number on the inside
of the front cover. Keep this manual and invoice in a safe and dry place for future refer-
ence.
GENERAL SAFETY WARNINGS AND PRECAUTIONS
KEEP WORK AREA CLEAN AND DRY. 1. Cluttered, damp, or wet work areas invite
injuries.
KEEP CHILDREN AWAY FROM WORK AREA. 2. Do not allow children to handle
this product.
STORE IDLE EQUIPMENT. 3. When not in use, tools and equipment should be
stored in a dry location to inhibit rust. Always lock up tools and equipment, and
keep out of reach of children.
DO NOT USE THIS PRODUCT IF UNDER THE INFLUENCE OF ALCOHOL OR 4.
DRUGS. Read warning labels on prescriptions to determine if your judgement or
reexes are impaired while taking drugs. If there is any doubt, do not attempt to
use this product.
USE EYE, HAND, AND HEARING PROTECTION. 5. Wear ANSI approved safety
impact goggles, hearing protection, and heavy-duty work gloves when using this
product.
DRESS SAFELY. 6. Do not wear loose clothing or jewelry, as they can become
caught in moving parts. Wear a protective hair covering to prevent long hair from
becoming caught in moving parts. If wearing a long-sleeve shirt, roll sleeves up
above elbows.
DO NOT OVERREACH.7. Keep proper footing and balance at all times to prevent
tripping, falling, back injury, etcetera.
REV 05j; 07f; 09a
