SKU 94944 PAGE 16
PARTS LIST
Part Description Qty
1 Screw M8X35 4
2 Spring Washer Ø8 4
3 Pin 4X17 1
4 Washer 18X12X1 2
5 Spring Seat 1
6 Ring 1
7 Spring 1
8 Collar 1
9 Oil Seal 1
10 O-ring 2
11 O-ring 2
12 Steel pole 4
13 Retainer Sleeve 1
14 Clip Ring 1
15 Clip Ring 68 1
16 Oil Bearing 1
17 Oil Bearing baffle 1
18 Orientation steel Ring 1
19 Rod 1
20 O-ring 1
21 Washer 1
22 O-ring 3
23 Ram 1
24 Ram baffle 1
25 Front oil Bearing 1
26 Dead block 1
27 Profiled block 1
28 Cylinder 1
29 Black oil bearing 1
30 Six Gear 1
31 Ram 1
32 O-ring 40x5 2
33 Piston pin 1
34 Piston 1
Part Description Qty
35 Connecting Rod 1
36 Needle Bearing NK121918 1
37 Screw M5x25 4
38 Spring Washer 5 6
39 Washer 5 6
40 Crank Case Cover 1
41 Feather Key 1
42 Clutch Plate 8
43 Spring 8
44 Fifth Gear 1
45 Plastic sheet 1
46 fourth Gear 1
47 Slip Plate 1
48 Needle Plate K14X18X13 2
49 Roll turn outside the needle 1
50 Needle Bearing HK1816 2
51 Third Crank Shaft 1
52 Pin B4X8 1
53 Second Four Gear 1
54 Clip Ring 40 1
55 Washer 35X18X1 2
56 Needle Plate 1
57 Crank Case 1
58 Screw M5X35 2
59 MI Ring 1
60 Screw ST4X35 2
61 Damping Seat 1
62 Damping Spring 1
63 Damping closure rail 1
64 Washer 1
65 Clip Ring 1
66 Ball Bearing 6002 1
67 O-ring 1
68 Gear Cover 1
