SKU 95504 Page 2
Specifications
Save This Manual
You will need the manual for the safety warnings and precautions, assembly
instructions, operating and maintenance procedures, parts list and diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep the manual and invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in
damp or wet locations. Don’t expose to rain. Keep work area well lighted. Do
not use electrically powered tools in the presence of flammable gases or
liquids.
3. Keep children away. Children must never be allowed in the work area. Do
not let them handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry
location to inhibit rust. Always lock up tools and keep out of reach of
children.
5. Do not force tool. It will do the job better and more safely at the rate for
which it was intended. Do not use inappropriate attachments in an attempt
to exceed the tool capacity.
ITEM
Overall Dimensions
Handle Dimensions
Inlet Size
Max. Rated Air Pressure
Air Consumption
Maximum Speed
Wheel Material
Wheel Dimensions
Arbor Diameter
Spindle Thread
Net Weight
DESCRIPTION
7-1/2” L x 5” W x 3-3/4” H
1”Dia. x 3-1/8”L (left side only)
1/4” - 18 NPT Female thread
90 PSI
6 CFM @90 PSI
10,000 RPM
Resin bonded aluminum oxide grit
4” Diameter x 1/4”Thickness
5/8”
3/8”
2.65 Lbs.
