English
14
4. Selecting the driver bit
Screw heads or bits will be damaged unless a bit
appropriate for the screw diameter is employed to
drive in the screws.
5. Confirm the direction of bit rotation (Fig. 9)
The bit rotates clockwise (viewed from the rear
side) by pushing the R-side of the push button.
The L-side of the push button is pushed to turn the
bit counterclockwise. (See Fig. 9) (The
L
and
R
marks are provided on the body.)
CAUTION:
The push button cannot be switched while the
power tool is turning. To switch the push button,
stop the power tool, then set the push button.
6. Continuous drilling
The number of holes that can be drilled in concrete
after one recharge is shown in Table 3.
Table 3
* Use an adapter for a small diameter bit.
These data are for the referential values. The number of
holes that can be drilled varies according to the sharpness
of the used bit or the conditions of the concrete being
drilled.
CAUTION:
When using this unit continuously, the unit may
overheat, leading to damage in the motor and
switch. Please leave it without using it for
approximately 15 minutes.
HOW TO USE
CAUTION:
⅜
When using the light equipped hook, pay sufficient
attention so that the main equipment does not
fall. If the tool falls, there is a risk of accident.
⅜
Do not attach the tip tool except phillips bit to the
tool main unit when carrying the tool main unit
with the light equipped hook suspended from a
waist belt.
Injury may result if you carry the equipment
suspended from the waist belt with sharp tipped
components such as drill bit attached.
1. Using the light equipped hook
The light equipped hook can be installed on the
right or left side and the angle can be adjusted in
5 steps between 0 and 80 .
(1) Operating the hook
(a) Pull out the hook toward you in the direction
of arrow (A) and turn in the direction of arrow
(B). (Fig.10)
(b) The angle can be adjusted in 5 steps (0°, 20°,
40°, 60°, 80°).
Adjust the angle of the hook to the desired
position for use.
(2) Switching the hook position
CAUTION:
Incomplete installation of the hook may result in
bodily injury when used.
(a) Securely hold the main unit and remove the
