English
18
Lamp indications Status lamp
Charging time Lights Lights continuously
30 minutes until charging complete.
Charge
30 minutes red
time Charging time Lights Lights continuously
20 minutes until charging complete.
lamp
20 minutes orange
(red/ Charging time Lights Lights continuously
5 minutes until charging complete.
orange/
5 minutes green
green)
Overheat standby
Blinks
Lights for 0.3 seconds, off 0.3 seconds
Battery overheated. Unable to charge.
red
(Charging will commence when battery cools.)
Charge
Before charging
Blinks
Lights for 0.5 seconds, off 0.5 seconds
Power cord is connected to
status
red receptacle.
lamp
Charging complete
Lights Lights continuously
(red/
green
orange/
Charging Blinks
Lights for 0.1 seconds, off 0.1 seconds
Battery or charger malfunction.
green)
impossible orange ■■■■■■■■■■■
(2) Regarding the temperature of the rechargeable battery
The temperatures for rechargeable batteries are as shown in the table below, and
batteries that have become hot should be cooled for a while before being recharged.
Table 5 Recharging of batteries that have become hot
4. Disconnect battery charger from the receptacle
CAUTION:
Do not pull the plug out of the receptacle by pulling on the cord.
Make sure to grasp the plug when removing from receptacle to avoid damaging cord.
5. Remove the battery from the battery charger
Supporting the battery charger with hand, pull out the battery from the battery charger.
CAUTION:
● Repair is required if the receptacle is not secured properly or the power cord does not
stay in the receptacle. Consult your electrician. Using the charger in this condition
may lead to fire.
● If the charge status lamp is blinking orange rapidly (in 0.2 second intervals) and the
buzzer sounds intermittently for 5 seconds, check that the hole for connecting the
battery is not obstructed. Remove any obstructions. If no obstructions are found, the
battery or charger may be malfunctioned. Return both to your place of purchase.
● If the charge time lamp does not light when the power cord is connected to the
receptacle, disconnect the power cord, and check that the battery is attached correctly.
● The battery retains heat when used or left for prolonged periods in direct sunlight. In
this state, the charge time lamp flashes red, and the battery cannot be charged
immediately. Leave the battery inserted in the charger, and charging will commence
when the battery cools down.
Rechargeable batteries Temperatures at which the battery can be recharged
EB1830HL 32°F—122°F (0°C—50°C)
Table 4 Lamp indications
