13
2. Battery Charger
NOTE: The charging time may vary according to temperature and power source voltage.
Model DV14DMR DV18DMR
Motor DC motor
No-load speed Low 0–400/min 0–400/min
High 0–1,750/min 0–1,800/min
Capacity Drilling Brick (Depth 9/16"(14 mm) 5/8"(16 mm)
1-1/4" (30 mm)) (Soft Brick) (Soft Brick)
Wood (Thickness
1-25/32"
(45 mm)
2" (50 mm)
11/16" (18 mm)) (Soft Wood) (Soft Wood)
Metal (Thickness
1/2" (13 mm) 1/2" (13 mm)
1/16" (1.6 mm)) (Mild Steel or (Mild Steel or
Aluminum) Aluminum)
Screw Wood screw #20 × 3" #20 × 4"
Driver
(8 mm × 75 mm) (8 mm × 100 mm)
Small screw 1/4" (6 mm) 1/4" (6 mm)
Drill chuck capacity Maximum gripping diameter 1/2" (13 mm)
Battery Model EB14B EB1830HL
Type
Nickel cadmium battery
Nickel-Metal Hydride battery
Voltage DC 14.4 V DC 18 V
Charging & discharging
about 1,000
frequency
Weight 5.5 lbs. (2.5 kg) 5.9 lbs. (2.7 kg)
SPECIFICATIONS
1. Cordless Hammer Drill
Model UC14YFA UC24YJ
Input power source Single phase: AC 120 V 60 Hz
Charging time Approx. 50 min. Approx. 28min
(At a temperature of 68°F (20°C))
Charging voltage DC 7.2–14.4 V DC 7.2–24 V
Charging current DC 2.6 A DC 7.5 A
Weight 1.3 lbs. (0.6 kg) 2.2 lbs. (1.0 kg)
<UC24YJ for DV18DMR>
Charge Time Lamp
Charge
Status Lamp
Caution Plate
Nameplate
Battery
Installation Hole
Fig. 3
