— 15 —
English
2 Insert the fuel cell into nailer.
3 Insert the stem of fuel cell into the hole of adaptor.
4 Close the cell cover.
(4) Remove the finger from the trigger and press the push
lever against the workpiece with pulling back the
feeder knob.
Ⅺ THE NAILER MUST NOT OPERATE.
(3) INSERT FUEL CELL INTO NAILER.
1 Pulling the latch and open the cell cover.
Ⅺ THE PUSH LEVER AND TRIGGER MUST MOVE
SMOOTHLY with pulling back the feeder knob.
(2) Installing the battery.
Do not operate the push lever or trigger while installing
the battery.
Make sure the battery indicator light is flashing green.
If the battery indicator light is flashing red, the battery
doesn’t have enough power and it needs to be charged.
BATTERY INDICATOR LIGHT
Flashing GREEN: Enough power remaining (The light
turns steady during operation).
Flashing RED: Insufficient power remaining (The light
turns steady during operation).
OFF: The battery is extremely empty. Charge the
battery.
Trigger
Push lever
Feeder knob
Handle
Latch
Battery
Pull out
Insert
Battery indicator
light
Depress
push lever
Feeder knob
Do not pull trigger
Fuel cell
Cell cover
Adapter
Stem
Fuel cell
Latch
Cell cover
Stem
Fuel cell
Adapter
