Power Source and Factory Options Stock No. Description Qty. Price
Big 40
®
Diesel CC #907 171 CSA model with engine gauges and automatic idle
Big 40
®
Diesel CC/CV #907 170 CSA model with engine gauges and automatic idle
#907 170-03-1 CSA Deluxe model w/ automatic idle, engine gauges, welding meters,
AC/DC polarity switch and high kW option
Field Kit Accessories
Weld Ammeter and Voltmeter Kit #195 131 Standard on deluxe model
Battery Voltmeter #195 454
DC Polarity Switch Kit #043 942 Changes DC polarity positive to negative
AC/DC Polarity Switch Kit #195 095 For CC/CV models. Standard on deluxe model
Cold Weather Starting Aid Kit #195 056 120 V block heater
Lockable Fuel Cap Flame Arrestor Kit #043 947 Padlock not included
Spark Arrestor Muffler Kit #195 012 Horizontal externally mounted
Vandalism Lockout Kit #195 118 Lockable front control panel and engine compartment
Cable Holder #043 946 Saddle-bag-style. Fastens to machine
Roll Cage/Drip Pan #194 918
Canvas Cover #194 683 Field. Cannot be used with cable holder
Stick Accessories
Accessory Kits #173 851 2/0, 350 A, 100% duty cycle, 50 ft (15 m) stinger, 50 ft (15 m) work clamp
#043 952 2/0, 300 A, 100% duty cycle, 100 ft (30.5 m) stinger, 50 ft (15 m) work clamp
MIG/Flux Cored Accessories
Millermatic
®
Passport
®
Plus #907 401 Includes gas bottle and MVP. See Lit. Index No. DC/12.53
SuitCase
X-TREME
8VS #300 093 See Lit Index No. M/6.41
SuitCase
X-TREME
12VS #195 500 See Lit Index No. M/6.41
SuitCase
8RC #194 938 See Lit Index No. M/6.5
SuitCase
12RC #194 940 See Lit Index No. M/6.5
MIG (GMAW)/Flux Cored (FCAW) Guns See Lit Index Nos. AY/15.0, AY/16.0 and AY/17.0
Spoolmatic
®
30A Spool Gun #130 831 Requires WC-24 Control. See Lit. Index No. M/1.73
WC-24 Control #137 549 See Lit. Index No. M/1.5
XR
Wire Feeder Control and Guns See Lit. Index No. M/1.7, M/1.71, and M/1.73
TIG Accessories
Dynasty
®
200 Series See Lit Index No. AY/4.8
High Frequency Arc Starters See Lit. Index No. AY/5.0
Remote Controls
RHC-3GD34A #041 122 CC models only, hand control
RHC-14 #129 340 CC/CV models only, amperage or voltage control
RFCS-14 HD #194 744 CC/CV models only, foot control
RMLS-14 #129 337 CC/CV models only, momentary and maintained contact switch
RCC-14 #151 086 CC/CV models only, fingertip control
RCCS-14 #043 688 CC/CV models only, fingertip control
Remote Control Extension Cords See page 6
Trailers and Hitches
4-West Trailer #042 801 4-wheel steerable implement trailer
HWY-224 Trailer #043 805 Trailer with lights, fenders and 2 in ball hitch
OFR-224 Trailer #043 802 Trailer with 2 in ball hitch
Lunette Eye, 2-1/2 in #043 824 Replaces the 2 in ball hitch on the HWY-224 or OFR-224
Cable Tree #043 826 Trailer mounted cable holder for HWY-224, OFR-224 or HWY-430
HWY-430 Trailer #043 806 Hitch required
Ball Hitch, 2 in #043 864 For HWY-430 only
Lunette Eye, 3 in #043 863 For HWY-430 only
Date: Total Quoted Price:
Ordering Information
