Mounting the camera using the velcro strap:
1. Attach the rubberized patch to the bottom of the helmet grip.
2+3. Place the helmet grip on the helmet, and thread the velcro strap
through the helmet grip.
4. Secure the velcro strap by fastening
it through the helmet vents.
5. Slide the camera into the helmet grip,
and adjust the angle of the camera
makig sure it's tight
Mounting the camera using the handlebar grip:
1. Place the handlebar grip on the handlebar.
2. Add the screw and nut to hold the handlebar grip securely.
3. Slide the camera into the handlebar grip and make sure the handlebar grip is locked
with the camera.
4. Adjust the angle of the camera.
9
10
V) Camera Mounting Description
The camera can be mounted in a number of ways using the straps and the Velcro patch
provided. Please follow the methods of mounting as suggested below:
Fixing the position of the camera.
a) Turn it left to screw the camera tight to fix it into position.
b) Turn it right to unscrew the camera.
Mounting the camera onto the helmet using the
silicon rubber strap
1. Attach the rubberized patch to the bottom of the helmet grip.
2.+3. Thread the silicon rubber strap through the helmet grip.
4. Mount the helmet grip to the helmet using the silicon rubber strap.
5. Slide the camera into the helmet grip.
6. Adjust the angle of the camera making sure it's tight.
Turn it left to screw
tight
Turn it right to
unscrew
#1
#2 #3
#4 #5
#6
#1
#2
#3
#4
#5
#1
#2
#3
#4
