Please call 1-800-8-BATTERY for information on how to recycle this battery.
. ACCESSORIES
CAUTION:
To prevent the risk of injury, only use accessory or attachment for its stated purpose.
If you need any assistance for more details regarding these accessories, ask your
local service center.
. SPECIFICATIONS
MAIN UNIT
Model EY3544
Motor DC Motor 18 V
Length of Strokes 23mm (7/8")
Strokes per Minute 0 ~ 2700 spm
Type of Blade shank 13 mm (1/2") universal reciprocating saw blade
Overall length 491 mm (19 - 5/16")
Weight (with battery pack) 3.9 k
, (8.7 lbs)
BATTERY PACK
Model EY9251
Storage battery Ni-MH Battery
Battery voltage 18 V DC (1.2 V × 15 cells)
BATTERY CHARGER
Model EY0110
Electrical rating See the rating plate on the bottom of the charger.
Weight 0.78 k
,
(1.72 lbs.)
Charging time
7.2V 9.6 V 12V 15.6V 18V 24V
1.2Ah
EY9065
EY9066
EY9080
EY9086
EY9001
EY9006
20min.
1.7Ah
EY9180
EY9182
EY9101
25min.
2.0Ah
EY9168 EY9106 EY9136 EY9117
30min. 30min. 60min.
3.0Ah
EY9200 EY9230 EY9210
45min. 90min.
3.5Ah
EY9201 EY9231 EY9251
55min. 65min.
NOTE:
This chart may include models that are not available in your area.
Please refer to the catalogue.
