6 REPLACEMENT PARTS LIST
NOTE:
*B=only available as set
*C=available individually
Ref.No. Part No. Part Name & Descriptions Remarks Per Unit
1 WEY6105K3078 HOUSING AB SET 1
2 EYT103L6807 CHUCK FASTENING SCREW 1
4 EY6406Y3228 CLUTCH HANDLE 1
5 WEYT107L0457 CLICK SPRING A 1
6 WEYT107L0637 ADJUSTING SCREW 1
7 WEYT107L0167 CLUTCH SPRING 1
8 EY6406L0578 CLUTCH PLATE 1
9 WEY7000L6967 STEEL BALL *B 5 (12pcs/PK) 12
10 WEYT107L1067 DRIVING BLOCK 1
11 EY6481L0357 THRUST PIN SET *C 2.5*33.6 2
12 WEY6105L1468 RING GEAR 1
13 WEY6105L1368 PLANET GEAR B *B (3pcs/PK) 3
14 EY6200B0857 THRUST PLATE 1
15 WEYT104L1357 CARRIER B 1
16 WEY6481L1458 RING GEAR A 1
17 WEYT107L1357 PLANET GEAR *B (3pcs/PK) 3
18 WEYT104L1107 CARRIER A 1
19 EY6101L1477 RING GEAR B 1
20 WEY6105L1378 PLANET GEAR A *B (3pcs/PK) 3
21 EY6481L0887 THRUST PLATE 1
22 EY6230L6027 SCREW *C K3-6 2
23 WEYT104L0027 MOTOR MOUNTING PLATE 1
24 WEY6105L1008 DC MOTOR 1
25 WEYT107Y3237 H/L CHANGE HANDLE 1
26 WEYT107Y2007 SWITCH 1
27 EY6230L6037 SCREW *C K3*5 2
28 EY6481L0207 DUST PREVENTIVE PLATE 1
29 WEYT602Y3247 F/R SELECTOR HANDLE 1
30 WEYT107L2567 HEAT SINK 1
31 WEY6403L6007 TAPPING SCREW 2.6*5 1
32 WEY6105K9038 TORX TAPPING SCREW *C K3*18 8
33 WEY6105L1458 GEAR BOX BLOCK 1
- WEY6405K7018 TOOL CASE 1
- WEY6105K8108 OPERATING INSTRUCTIONS 1
**Battery Pack, and Keyless Chuck are available as an optional accessory. See the nearest sales dealer for details.
***For replacement parts of charger, see the charger service manual.Charger complete set is available as an optional accessory.
See the nearest sales dealer for details.
9
EY6105-U1
