7 REPLACEMENT PARTS LIST
NOTE:
*B=only available as set
*C=available individually
Ref.No. Part No. Part Name & Description Remarks Per Unit
1 WEY6803K3078 HOUSING AB SET 1
2 WEY6813H3117 CHUCK COVER 1
3 WEY6803K3127 CHUCK HANDLE 1
4 WEY6813L0427 BALL GUIDE 1
5 WEY6813L0437 CHUCK SPRING STRIKE PLATE 1
6 WEY6813L1917 STEEL BALL 7 1
7 WEY6813L0917 CHUCK SPRING 1
8 WEY6803L3997 SEAL A 1
9 WEY6803L3987 SEAL B 1
10 WEY6803L0927 PISTON APPLYING POWER SPRING 1
11 WEY6803Y3247 F/R HANDLE 1
12 WEY6803L1167 C-TYPE RING 1
13 WEY6803L3137 FELT 1
14 WEY6803L0467 SNAP RING 1
15 WEY6803L1707 LOCK PIN *B (2PCS/PK) 2
16 WEY6803Y3227 CLUTCH HANDLE 1
17 WEY6803Y3297 CLUTCH CASE 1
18 WEY6813L4957 BEARING 1
19 WEY6803L0477 SNAP RING 1
20 WEY6803L4067 SPINDLE ASSEMBLY 1
21 WEY6803L0057 SPINDLE 1
22 WEY6813L1927 STEEL BALL *B 5, (6PCS/PK) 4
23 WEY6813L0347 O RING 1
24 WEY6803L1237 STRIKER 1
25 WEY6813L0327 O RING 1
26 WEY6813L0317 O RING 1
27 WEY6803L4907 CLUTCH ASSEMBLY 1
28 WEY6813L0907 PIN *B 5x4 (2PCS/PK) 2
29 WEY6813L0477 SNAP RING 1
30 WEY6803L0857 THRUST PLATE *C 2
31 WEY6803L1247 PISTON ASSEMBLY 1
32 WEY6803L4627 HAMMER 1
33 WEY6803L0977 O RING 1
34 WEY6803L1987 PISTON 1
35 WEY6812L0847 THRUST PLATE *B (2PCS/PK) 2
36 WEY6803L1257 UNIVERSAL COUPLING 1
37 WEY6803L0387 NEEDLE BEARING 1
38 WEY6803L4057 INTERMEDIATE SHAFT ASSEMBLY 1
39 WEY6803L1467 MOTOR ROTOR ASSEMBLY 1
40 WEY6803L1187 MOTOR STATOR ASSEMBLY 1
41 WEY6803L2307 MOTOR BRUSH ASSEMBLY 1
42 WEY6803L2007 SWITCH ASSEMBLY 1
43 WEY6803L2017 SWITCH 1
44 WEY6803L2337 LED COVER 1
45 WEY6803L0417 BASE PLATE BLOCK 1
46 WEY6803L2407 TERMINAL BLOCK 1
47 WEY6813L3137 TRIGGER COVER 1
48 WEY6261B6027 SEMS SCREW *C K3-6 2
49 WEY6230K9218 TORX TAPPING SCREW *C K3X20 14
50 WEY6803L0137 CUSHION RUBBER 1
51 WEY3561L3417 SHOULDER STRAP 1
52 WEY6803L4538 POWER SHAFT ASSEMBLY 1
- WEY6811X5537 GREASE ASG-22 1
- WEY6812T7918 GREASE 1
- WEY9629K7018 TOOL CASE 1
- WEY6803K4968 JIG (PLATE & CAP) 1
- WEY6803K8108 OPERATING INSTRUCTIONS 1
** Battery Pack and Bit Adaptor are available as an optional accessory. .
See the nearest sales dealer for details.
*** For replacement parts of charger, see the charger service manual.
Charger complete set is available as an optional accesso ry. See the nearest sales dealer for details.
12
EY6803-U1
