6 REPLACEMENT PARTS LIST
NOTE:
*B=only available as set
*C=available individually
Ref.No. Part No. Part Name & Description Remarks Per Unit
1 WEY6950K3078 HOUSING AB SET 1
2 EY6481L0177 CLICK SPRING 1
3 WEY6450L6808 CHUCK FASTENING SCREW 1
5 WEY6950Y3228 CLUTCH HANDLE 1
6 WEY6450L0638 ADJUSTING SCREW 1
7 WEY6450L0578 CLUTCH PLATE 1
8 WEY6450L0168 CLUTCH SPRING *B (6pcs/PK) 6
9 WEY6813L1927 STEEL BALL *B (6pcs/PK) 5 6
10 WEY6450L0388 PIN *B (6pcs/PK) 5.3*20.3 6
11 WEY6950L1078 DRIVING BLOCK 1
12 EY6283L0377 PIN *B (6pcs/PK) 3.175*7.2 6
13 EY6901L1107 CARRIER 1
14 WEY6450L1488 RING GEAR 1
15 WEY6450L1348 PLANET GEAR *B (3pcs/PK) 3
16 WEY6450L0858 THRUST PLATE 1
17 WEY6450L1768 GEAR CASE 1
18 EY6406K9038 TORX TAPPING SCREW *C K3-12 4
19 WEY6450L1128 CARRIER A 1
20 WEY6450L1358 PLANET GEAR A *B (3pcs/PK) 3
21 WEY6200B1468 RING GEAR B 1
22 WEY6950L1118 CARRIER 1
23 WEY6950L1478 RING GEAR 1
24 EY6230L1367 PLANET GEAR *B (4pcs/PK) 4
25 WEY6450L0868 THRUST PLATE 1
26 WEY6950L0358 PIN *B (2pcs/PK) 2
27 WEY6450L0178 CLICK SPRING A 1
28 WEY6450Y3238 H/L CHANGE HANDLE 1
29 WEY6405Y3248 F/R SELECTOR HANDLE 1
30 EYT184L6077 SCREW *C K4-6 2
31 WEY6450L0028 MOTOR MOUNTING PLATE 1
32 WEY6450L1008 DC MOTOR 1
33 WEY6450S6028 SEMS SCREW *C K3-5 2
34 WEY6950Y2008 SWITCH 1
35 EY6406L2568 HEAT SINK with a screw 1
36 EY6230L0207 DUST PREVENTIVE PLATE 1
37 EY6230K9218 TORX TAPPING SCREW *C K3-20 9
38 WEY6950L1458 GEAR BOX BLOCK 1
39 WEY6450K4628 SIDE HANDLE 1
- WEY6950K8108 OPERATING INSTRUCTIONS 1
**Battery Pack, Keyless Chuck, and Tool Case are available as an optional accessory.
See the nearest sales dealer for details.
***For replacement parts of charger, see the charger service manual.
Charger complete set is available as an optional accessory. See the nearest sales dealer for details.
10
EY6950-U1
