Model W1774 18 Gauge Brad Nailer
-5-
The Model W1774 is designed to be
operated at 60-100 PSI using clean,
dry, regulated, compressed air. Do not
exceed the 120 PSI maximum operating
pressure for your model.
Before using your nailer, regulate the
air pressure to find the optimum setting
within the specified operating range.
Start by testing the nailer at a low
setting, then increase the air pressure as
needed for satisfactory results.
An in-line filter/lubricator/regulator unit,
can be installed as depicted in Figure 1.
This filter/lubricator/regulator unit
will protect your tool from damaging
water build-up, allow you to adjust and
maintain regulated air pressure to your
tool, and save you the inconvenience of
having to manually lubricate your tool
every time you use it.
If you plan on installing a filter/
lubricator/regulator unit in your
compressed air system, always follow the
connection instructions that come with
the unit.
Figure 1. Typical filter/lubricator/regulator installation order.
Compressed Air System
Exceeding the maximum permissible
operating pressure may damage the
nailer and cause it to malfunction.
To protect yourself from personal
injury, DO NOT allow the air pressure
to exceed the recommended
pressure for this nailer!
