Model W1793/W1794 Professional Spray Gun
-11-
Lubrication
Lubricate the following areas with
spray gun lube after cleaning:
A. Atomizing Cap Threads
B. Air Valve Packing
C. Trigger Pin
D. Air Flow Control Valve
E. Pattern Control
F. Fluid Control Knob
After each cleaning, apply a thin film
of petroleum jelly to the needle spring
before reassembling.
Figure 14. Lubrication points.
A
B
C
D
E
F
