Model W1795/W1801 Deluxe Spray Gun
-5-
SETUP
Inventory
This tool has been carefully packaged for safe transportation. If you notice the tool
has been damaged during shipping, please contact your authorized Shop Fox dealer
immediately.
Unpacking
The following is a description of the main components shipped with the Model W1795/
W1801. Lay the components out to inventory them.
Note: If you can't find an item on this list, check the mounting location on the tool
or examine the packaging materials carefully. Occasionally we pre-install certain
components for safer shipping.
W1795 Inventory (Figure
1) Qty
A. Spray Gun . .............................. 1
B. Cup 600 ml ............................... 1
C. Cleaning Brush ........................... 1
D. Service Wrench .......................... 1
E. Filters ..................................... 2
F. Baffle Wrench ........................... 1
W1801 Inventory (Figure
2) Qty
A. Spray Gun . .............................. 1
B. Cup 600 ml ............................... 1
C. Cleaning Brush ........................... 1
D. Service Wrench .......................... 1
E. Filters ..................................... 2
F. Baffle Wrench ........................... 1
Figure 1. Model W1795 inventory.
B
C
D
F
E
A
Figure 2. Model W1801 inventory.
B
C
D
F
E
A
