Tool Model Fastener Type Fastener SKU Gauge Length
FN1664 SB16-1.25 16 1-1/4” (32mm)
FN1664 SB16-1.50 16 1-1/2” (38mm)
FN1664 SB16-1.75 16 1-3/4” (45mm)
FN1664 SB16-2.00 16 2” (50mm)
SB16-2.50 16 2-1/2” (63mm)
TOOL SPECIFICATIONS
A
ll demensions in inches unless otherwise specified.
-5-
Operating Pressure:
70 to 120 p.s.i.g. (4.9 to 8.43 kg/cm
2
). Select the operating pressure within in this range for best fastener
performance.
Air Consumption:
The FN1664 requires 3.9 cubic feet per minute or C.F.M. (110.4 liters per minute or LT/MIN) of free air at 80PSI
(5.6 kg/cm
2
) to operate at a rate of 60 fasteners per minute. To determine the appropriately sized air
compressor, take the actual rate at which the tool will be run and compare the required C.F.M. (LT/MIN) to the
compressors free air delivery (C.F.M./ LT/MIN) at 80 PSI (5.6 kg/cm
2
).
For example, if your fastener usage averages 30 fasteners per minute, you need 50% of the tools C.F.M.
required to operate the tool at the rate of 60 fasteners per minute. In this case, be sure that your air compressor
can deliver a minimum of 1.90 C.F.M. (55.2 LT/MIN) at 80 PSI(5.6 kg/cm
2
) for optimum performance.
FASTENER SPECIFICATIONS
* Stainless steel fasteners also available in certain sizes. Visit www.BOSTITCH.com for further details.
NOTE:
BOSTITCH tools have been engineered to provide superior customer satisfaction and are designed to achieve
maximum perfomance when used with precision BOSTITICH fasteners engineered to the same exacting
standards. BOSTITCH cannot assume responsibility for product performance if our tools are used with
fasteners or accessories not meeting the specific requirements established for genuine BOSTITCH
fasteners and accessories.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
FN1664
D
escription 16ga Finish Nailer
Engine Type Oil-Free
O
peration Pressure Range 70-120 PSI (4.9 to 8.43kg/cm
2
)
M
aximum Operation Pressure 120 PSI (8.43 kg/cm
2
)
Fastener Type SB16 Series
F
astener Gauge 16 Gauge
Fastener Range 1” – 2-1/2” (25mm–63mm)
M
agazine Capacity 110
Length 11-7/8” (301.6mm)
Width 3-3/8” (85.7mm)
Height 11-3/8” (288.9mm)
Weight 3.9 lbs. (1.7kg)
FN1664
Straight Finish Nails
