Device Menu Screen
2M46-04R/2M46-04RDC User’s Guide 5-13
The following explains each Device Menu screen field as shown in
Figure 5-7:
DEVICE CONFIGURATION
The Device Configuration screen provides access to the Local
Management screens that are used to configure the 2M46-04R and also to
the Device Specific Configuration menu screen. The Device Specific
Configuration menu screen provides access to the screens that allow the
user to check the 2M46-04R resources and set operating parameters
specific to each port. For details about the Device Configuration Menu
screen, refer to Section 5.6. For details about the Device Specific
Configuration menu screen, refer to Section 5.11.
DEVICE STATISTICS
The Device Statistics screen provides statistics and performance
information for the 2M46-04R. For details about this screen, refer to
Section 5.18.
NETWORK TOOLS
The Network Tools function resides on the 2M46-04R and consists of a
series of commands that allow the user to access and manage network
devices. Section 5.22 explains how to use the Network Tools utility.
NOTE
If the terminal is idle for a modifiable period of time, the
Password screen redisplays and the session ends.
