Figure 5-16 Device Specific Configuration Menu Screen
The following explains each selectable item in the Device Specific
Configuration Menu screen:
SYSTEM RESOURCES
The System Resources screen displays the amount of FLASH memory,
DRAM and NVRAM installed, indicates the amount of available memory
and provides information on 2M46-04R operation. For details, refer to
Section 5.12.
HIGH SPEED INTERFACE CONFIGURATION
The High Speed Interface Configuration screen provides access to the
Fast Ethernet Interfaces screen and the HSIM screens. For details, refer to
Section 5.13.
FLASH DOWNLOAD
The FLASH Download screen allows the user to download a new
firmware image to FLASH memory on the 2M46-04R. For details, refer
to Section 5.15.
Firmware Revision: XX.XX.XX
Device Specific Configuration
SYSTEM RESOURCES
HIGH SPEED INTERFACE CONFIGURATION
FLASH DOWNLOAD
PORT REDIRECT FUNCTION
BROADCAST SUPPRESSION
