Installing the In-Sight 2000
11
Summary of Processor Specifications
A summary of In-Sight 2000 specifications appears below in Table 1.
Table 1. In-Sight 2000 Processor General Specifications
Specification Description
Model Number Cognex In-Sight 2000
Part Number 800-5214-1
Processor Texas Instruments C-6000 series DSP architecture
Memory n Job & program storage: 4 MB non-volatile flash memory for up to 20 jobs
n Image acquisition and processing: 16 MB SDRAM
n VGA display: 1 MB
Input n 10-button Control Pad with a 3-m (10 ft) cable
n Keyboard and mouse entry and navigation from a PC using In-Sight PC Server software
Display n 640 x 480 VGA output through a standard 15-pin D-sub connector
n Color graphics overlay
I/O n Built-in: 2 discrete inputs and 2 discrete outputs
n External: 8 discrete inputs and 8 discrete outputs requires optional I/O Expansion Module)
Communications
Two RJ-45 ports using RS-232C protocol up to 115Kb
(RJ-45 to DB-9 adapter supplied).
Light Control
Dynamic control for variable-intensity lights (requires an optional Cognex light module)
Power Consumption
24 ± 5% VDC, 1 A (includes the camera lights, and an I/O Expansion module). Connected by screw
terminals on a detachable 2-pin terminal plug.
Mechanical n Cast-aluminum enclosure; no moving parts
n Four ¼-in (6-mm) mounting holes
n Dimensions:
• 292.6 (width) x 142.5 (depth) x 45.5 mm (height)
• 11.52 (width) x 5.61 (depth) x 1.79 in (height)
n Weight: 966 g (33.8 oz)
Environmental
n Operating temperature: 10 to 50°C
n Operating humidity: 10 to 90%, non-condensing
n Storage temperature: –10 to 65°C
n Storage humidity: 10 to 90%, non-condensing
