Auto CR
This selects whether the printer performs a carriage-return/line-
feed (CR-LF) operation whenever the printer position goes
beyond the right margin. If this setting is
Off
, the printer does not
print any characters beyond the right margin and does not
perform any line wrapping until it receives a carriage-return
character. This function is handled automatically by most
software applications.
Auto LF
If you set this option to
Off
, the printer does not send an automatic
line-feed (LF) command with each carriage-return (CR). If this is
set to
On
, a line-feed command is sent with each carriage-return.
You should set this to
On
if your text lines overprint each other.
Bit Image
If you set this parameter to
Dark
or
Light
, the printer is able to
emulate the graphics densities set with the printer commands. If
you select
Dark
, the bit image density is high, and if you select
Light
, the bit image density is low.
If you select BarCode, the printer converts bit images to bar codes
by automatically filling in any vertical gaps between dots. This
produces unbroken vertical lines that can be read by a bar code
reader. This mode will reduce the size of the image when printed,
and may also cause some distortion when printing bit image
graphics.
ZeroChar
Selects whether the printer prints a slashed or unslashed zero.
This is useful for distinguishing between an uppercase O and a
numeric 0 when printing program listings, for example.
