5
BASIC ANTENNA CONNECTION
If no Video Signal is present, the TV will shut itself
off in about 10 minutes. If the TV is tuned to the
AV channel and there is no Video Signal present,
the screen will remain blank and the TV will shut
itself off in about 10 minutes.
Use Auto Program as described on page 9 to
setup channels that are available in your area. Use
the
CH + / -
buttons to scan available channels.
HELPFUL HINTS
1
If your
antenna has a round cable
(75 )
on the end, then you are ready to connect it
to
the TV. Con
tinue with step 2.
If your antenn
a has flat t
win
lead wire
(300 ), you first need to switch the antenna
wires to the screws on a 300 to 75 adapter
(not supplied with TV).
If you have a Cable Converter Box :
Connect the Cable TV signal to the Cable
Si
gnal IN(put) plug on the C
onverter.
2
Push the round end of the adapter or antenna
cable onto the 75 jack
on the rear of the
cable onto the 75 jack on the rear of the cable onto the 75 jack
TV. If the round end of the an
tenna cab
le is
threaded,
screw it d
own tight.
A
A
combination antenna receives normal broadcast channels (VHF-2-13 and U
HF-14-69). Your connection is easy since
there is only one 75
ohm ante
nna plug on the back of your TV - and that’s where the antenna goes.
75
1
2
75‰
Antenna Connection
300 to 75
Adapter
Combination
VHF/UHF Antenna
(Outdoor or Indoor)
Twin L
ead
Wire
Round Cable
75
Back of TV
BASIC CABLE CONNECTION
75
75‰
1
Back of TV
Cable signal
coming from
Cable Company
Jack Panel Back of TV
Direct Cable Connection
75 Round
Coaxial Cable
1
Connect the Cable TV
cable directly to
the
75 jack o
n the TV.
I
f cable TV signal
into your home is a single cable (
75 ohm)
the connection to the TV is easy.
