16
The disk data is being accessed from the
network and a read/write error occurs during
the process.
The NAS is connected to the network.
The 10GbE network expansion card is
installed.
No 10GbE network expansion card is installed.
The NAS is being accessed from the network.
A hard drive read/write error occurs.
The disk data is being accessed.
The hard drive can be accessed.
Flashes blue
every 0.5 sec
1. A USB device (connected to the front USB
port) is being detected.
2. A USB device (connected to the front USB
port) is being removed from the NAS.
3. The USB device (connected to the front
USB port of the NAS) is being accessed.
4. The data is being copied to or from the
external USB or eSATA device.
A front USB device is detected (after the
device is mounted).
1. No USB device is detected.
2. The NAS has finished copying the data to
or from the USB device connected to the
front USB port.
The eSATA device is being accessed.
No eSATA device can be detected.
Storage
Expansion
Port
Status
2
No expansion enclosures are detected.
Expansion enclosures are detected.
The expansion enclosures are being accessed.
The 10 GbE network expansion function is only supported by the TS-879 Pro, TS-1079 Pro,
TS-879U-RP, TS-1279U-RP, TS-EC879U-RP, TS-EC1279U-RP, TS-1679U-RP, TS-EC1679U-RP,
TS-870U-RP, TS-1270U-RP, TS-EC1279U-SAS-RP, TS-EC1679U-SAS-RP, SS-EC2479U-SAS-RP,
SS-EC1879U-SAS-RP, and SS-EC1279U-SAS-RP.
The storage expansion port status LED is only supported by the TS-EC1279U-SAS-RP and
TS-EC1679U-SAS-RP, SS-EC2479U-SAS-RP, SS-EC1879U-SAS-RP, SS-EC1279U-SAS-RP.
