REF.# PART# DESCRIPTION QTY.
40 44-005 Pulley 1
41 44-006 Belt 1
42 40-022 Idler Pulley 1
43 400-018 3/8” - 16 x 2 ½” Bolt 1
44 44-016 Engine & Tank Base 1
45 40-273 Marking Guide 1
46 8802 ½” Clear Hose 6”
47 602-640 Thumb Screw 3/8” - 16 x 1 ¼” 3
48 40-189 Line Guide Arm 1
49 2110 Pivot Post Bearing 2
50 44-015 Front Caster Fork 1
51 400-121 5/8” – 11 Hex 2-Way Locknut 1
52 40-154 Machine Bushing ¾” x 14 1
53 925-108 5/8” – 11 x 8” Hex Bolt (Caster Axle) 1
54 40-154 Machine Bushing 5/8” x 14GA 2
55 29-597 Caster Wheel 2
56 44-022 Cable Arm 1
57 44-001 Control Cable 1
58 44-003 Transaxle 1
59 44-025 Spacer 2
60 44-125 Wheel & Tire 2
61 40-165 Retainer Ring 2
62 8800 ¼” Clear Vinyl Hose 45”
63 41-222 Grease Seal 2
64 8800 ¼” Clear Vinyl Hose 48”
65 44-008 Plug 2
66 44-007 Socket 2
67 41-115 ¾” Strainer 40 Mesh 1
68 500-100 ¼” x ¾” Bushing 2
69 8800 ¼” Clear Vinyl Hose 36”
4
SPRAY BOOM DRAWING & PARTS LIST
