HOW TO USE THE LASER SYSTEM

POWERING THE LASER

Batteries

WARNING

Ni-MHbatteriesmaycontainsmallamountsofharmfulsubstances.Besuretochargethebattery

beforeusingitforthefirsttime,andafternotusingitforanextendedlengthoftime.Chargeonlywith

specifiedchargersaccordingtodevicemanufacturer‘sinstructions.Donotopenthebattery,dispose

ofinfireorshortcircuit;itmayignite,explode,leakorgethotcausingpersonalinjury.Disposein

accordance with all applicable federal, state, and local regulations. Keep the battery away from

children.Ifswallowed,donotinducevomiting.Seekmedicalattentionimmediately

Recharging the Batteries

ThelaserisshippedwitharechargeableNi-MHbatterypack.

Note: TheapproximatechargeofthebatteriesisshownatthelefttopsideoftheLCD.

Thechargerrequiresapprox.10hourstochargeemptyrechargeablebatteries.

Forcharging,connecttheplugofthechargertotherechargejackofthebatterypack.

Neworlong-timeout-of-userechargeablebatteriesreachtheirbestperformanceafter

beingchargedandrechargedfivetimes.ForIndoorapplicationsthechargercanbe

usedasapowersupplyfortheGL.

Alkalinebatteriescanbeusedasabackup.Insert4D-cellbatteriesnotingtheplus

(+) and minus (-) diagrams inside the battery housing.

The batteries should only be charged when the laser is between 50° F and 104° F (10°C to

40°C). Charging at a higher temperature may damage the batteries. Charging at a lower

temperature may increase the charge time and decrease the charge capacity, resulting in

loss of performance and shortened life expectancy.

RC602 Radio Remote Control

Powering the RC602

1. Open the battery door using a coin or similar pry device to release the

batterydoortabontheRC602.RC602willbeshippedwithalkaline

batteries Rechargeable batteries can be used optional but need to

bechargedexternally

2.InserttwoAAbatteriesnotingtheplus(+)andminus(-)diagrams

inside the battery housing.

3.Closethebatterydoor.Pushdownuntilit“clicks”intothelocked

position.

Turning On/Off the Radio Remote Control

The radio remote control is a hand-held device that allows you to send operational commands to the laser

from a remote location.

Pressthepowerbuttontoturnontheradioremotecontrol.A“ ”andadditionalverticalbarsappearinthe

right corner of the remote’s top display line indicating the radio connection status between the laser and the

remote control.

Note

:Whentheremotecontrolisinitiallyturnedon,thestandarddisplay(modelnumberandsoftwareversion)

appearforthefirst3seconds,thentheaxessymbolsandlast-enteredgradeforeachaxisbrieflyappearin

theLCD.

Witheverybuttonpress,theLCDbacklightisactivatedandturnsoffautomaticallyifnobuttonispressedfor

8seconds.

To turn off the radio remote control, press and release the power button.

Note

:5minutesafterthelastbuttonpress,theremotecontrolturnsoffautomatically.
