Turbomachinery Package Specification Taurus 60 Compressor Set and Mechanical Drive
Main Lube Oil Duplex Filters
Type Self-Supporting Pedestal
Duplex Filters 10 Micron
Certification ASME, Section VIII, Division 1
Backup Lube Oil Pump Filter
Type Bowl Filter
Minimum/Maximum Operating Temperatures -54° to 135°C (-65° to 275°F)
Simplex Filter β X > 75 Micron
Lube Oil Vent Coalescer
Type Air/Oil Mist Eliminator
Maximum Working Temperature 93°C (200°F)
Orientation Vertical
Performance
100% removal of all droplets greater than 3 microns
and 99.5% removal of all droplets less than 3
microns.
Certification ASME, Division 1
Approximate Dimensions (Height x Diameter) 262 cm x 35.6 cm (103 in. x 14 in.)
Approximate Weight 195 kg (430 lb)
Lube Oil Vent Flame Arrestor
Orientation
Vertical, See Note (f)
Approximate Dimensions (Height x Diameter) 26 cm x 55 cm (10.3 in. x 21.6 in.)
Approximate Weight 26 kg (58 lb)
Strainers
Tank Fill 20 mesh
Gearbox Breather Vent (If Applicable) 40 mesh
Gas Producer Start-Up Strainer
70 Micron, See Note (g)
Gearbox Start-Up Strainer (If Applicable)
70 Micron, See Note (g)
Compressor Driven End Start-Up Strainer
70 Micron, See Note (g)
Compressor Exciter End Start-Up Strainer
70 Micron, See Note (g)
Lube Oil
Viscosity Grade ISO VG 32 (C32) Use When Ambient Temperature is <43°C (110°F)
Viscosity Grade ISO VG 46 (C46) Use When Ambient Temperature is >43°C (110°F)
Pour Point
Must Be At Least 6°C (11°F) Below The Lowest
Ambient Temperature)
Lube Oil Tank Capacity
2250 L (594 gal.), See Note (h)
Weight 2080 kg (4590 lb)
Construction Materials
Piping, Manifolds, and Tubing 316L Stainless Steel
Lube Oil Tank and Tank Covers
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Main Lube Oil Duplex Filter Housing and
Transfer Valve
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Backup Lube Oil Pump Filter Housing
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Lube Oil Vent Coalescer
Carbon Steel (Standard)
316L Stainless Steel (Optional)
Lube Oil Vent Flame Arrestor
Carbon Steel (Standard)
316L Stainless Steel (Optional)
