Turbomachinery Package Specification Taurus 60 Compressor Set and Mechanical Drive
Table 12. Air Inlet System Specifications
Air Inlet System
Pressure Drop Less Than 102 mm (4 in.) H
2
O with a Clean Air Filter
Ducting Loads Should Not Be Applied In Any Direction
Prefilter and Barrier Inlet Air Filter
Air Flow 17 m
3
/s (36,000 cfm)
Approximate Measurements
Height 229 cm (90.0 in.)
Width 225 cm (88.6 in.)
Length 167 cm (65.8 in.)
Weight 1406 kg (3100 lb)
Pressure Drop
Clean 44 mm (1.75 in.) water
Fouled 127 mm (5 in.) water
Self-Cleaning Barrier Type Air Filter
Fluid Clean-Dry Air
Air Quality See Note (a)
Minimum/Maximum Regulated Pressure Range 552 to 758 kPag (80 to 100 psig)
Intermittent Flow Rate (Est.) 0.25 nm
3
/min (9 scfm)
Pressure Drop
Clean 25 mm (1.0 in.) water
Fouled 76 mm (3.0 in.) water
Air Flow 17 m
3
/s (36,000 cfm)
Approximate Measurements
Height 239 cm (94.0 in.)
Width 232 cm (91.3 in.)
Length 620 cm (244.1 in.)
Weight 2500 kg (5500 lb) with filter elements
Marine / Offshore High Velocity Type Air Filter
Pressure Drop (Clean), HVL 53 mm (2.1 in.) water
Pressure Drop (Clean), HVX 61 mm (2.4 in.) water
Air Flow 17 cms (36,000 cfm)
Approximate Measurements
Height 206 cm (81.1 in.)
Width 198 cm (78.1 in.)
Length 153 cm (60.4 in.)
Weight 739 kg (1630 lb) with filter elements
Offshore / Coastal Medium Velocity Type Air Filter
Pressure Drop (Clean) - 3 stage 33 mm (1.3 in.) water
Pressure Drop (Clean) - 4 stage 53 mm (2.1 in.) water
Air Flow 17 cms (36,000 cfm)
Approximate Measurements
Height 280 cm (110.3 in.)
Width 280 cm (110.3 in.)
Length 312 cm (122.7 in.)
Weight 2056 kg (4532 lb) with filter elements (4 stage)
© 2009 Solar Turbines Incorporated. All rights reserved. TPS60CSMD/309
