ENGLISH
• Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
Accessories
The performance of your tool depends on the accessory
used. Black & Decker accessories are engineered to high
quality standards and designed to enhance the performance
of your tool. By using these accessories you will get the very
best from your too
Mains plug replacement (U.K. & Ireland only)
If a new mains plug needs to be fitted:
• Safely dispose of the old plug.
• Connect the brown lead to the live terminal in the new
plug.
• Connect the blue lead to the neutral terminal.
• Connect the green/yellow lead to the earth terminal.
Warning! Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 13 A.
• Use HSS router bits for softwood.
• Use TCT router bits for hardwood.
• You can use the tool without a guide (fig. N). This is
useful for signwriting and creative work. Only make
shallow cuts.
• Refer to the table below for common types of router bits.
Router bits (fig. O)
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regular cleaning.
Warning!
Before performing any maintenance, switch off
and unplug the tool.
• Regularly clean the ventilation slots in your tool using a
soft brush or dry cloth.
Description Application
Straight bit (1) Grooves and rebates
Trimming bit (2) Trimming laminates or hardwood;
accurate profiling using a template
Rebating bit (3) Rebates on straight or curved
workpieces
V-grooving bit (4) Grooves, engraving and edge
bevelling
Core box bit (5) Fluting, engraving and decorative
edge moulding
Cove bit (6) Decorative edge moulding
Ogee moulding bit (7) Decorative edge moulding
Rounding over bit (9) Rounding over edges
Dovetail bit (10) Dovetail joints
Chamfer bit (11) Chamfer edges
Technical data
Input voltage V
AC
220-240
Power input W 1,200
No-load speed
/min
8,000 - 27,000
Collet size 5/16" (8 mm) /
1/4" (6.35 mm) / 6 mm
Max. diameter of router bit mm 30
Max. depth of cut mm 55
Weight kg 3.6
BPRR1200
