! 8+<+4:/<+
3'/4:+4'4)+6+8,583+*(?;4';:.58/@+*
6+89544+23'?8+9;2:/43/962')/4-5,
/4:+84'2=/8+9'4*)53654+4:9=./).
)5;2*)';9+9+8/5;9.'@'8* We recom -
mend that all tool service be performed by a
Bosch Factory Service Center or Authorized
Bosch Service Station. SERVICE MEN:
Disconnect tool and/or charger from power
source before servicing.
!!
+'2+8:,58('::+8?6')19:.':'8+4+'8/4-
:.+/8+4*5,2/,+ If you notice decreased
tool performance or significantly shorter
running time between charges then it is time
to replace the battery pack. Failure to do so
can cause the tool to operate improperly or
damage the charger.
!"!
Your Bosch tool has been properly lubricated
and is ready for use.
!
The motor in your tool has been engineered
for many hours of dependable service. To
maintain peak efficiency of the motor, we
recommend it be examined every six months.
Only a genuine Bosch replacement motor
specially designed for your tool should be
used.
2+'4/4-
!5'<5/*'))/*+4:9'2='?9
*/9)544+)::.+:552'4*58
).'8-+8,853:.+65=+89;662?(+,58+
)2+'4/4- The tool may be cleaned most
effectively with com pressed dry air. 2='?9
=+'89',+:?-5--2+9=.+4)2+'4/4-:5529
=/:.)5368+99+*'/8
Ventilation openings and switch levers must
be kept clean and free of foreign matter. Do
not attempt to clean by inserting pointed
objects through opening.
+8:'/4)2+'4/4-'-+4:9
'4* 952<+4:9 *'3'-+
62'9:/)6'8:9Some of these are: gasoline,
car bon tetrachloride, chlorinated cleaning
solvents, ammonia and household detergents
that contain ammonia.
'/4:+4'4)+
!
WARNING
!
WARNING
!
CAUTION
-13-
Fine sanding and polishing re quire “touch”.
Select the most efficient speed.
When using polishing bonnets, always be sure
the excess string that secures the bonnet is
tucked well within the bonnet during operation.
$"
Work with brushes requires high speeds.
" "
1. Remember, the tips of a wire brush do the
work. Operate the brush with the lightest
pressure so only the tips of the wire come in
contact with the work.
2. If heavier pressures are used, the wires
will be overstressed, resulting in a wiping
action; and if this is continued, the life of the
brush will be shortened due to wire fatigue.
3. Apply the brush to the work in such a way
that as much of the brush face as possible is
in full contact with the work. Applying the side
or edge of the brush to the work will result in
wire breakage and shortened brush life.
""! !
Variable speed control must be used with
caution for driving nuts and bolts with socket
set attach ments. The technique is to start
slowly, increasing speed as the nut or bolt runs
down. Set the nut or bolt snugly by slowing the
drill to a stop. If this procedure is not followed,
the tool will have a tendency to torque or twist
in your hands when the nut or bolt seats.
CORRECT: Wire tips doing the work.
INCORRECT: Excessive pressure can cause wire breakage.
