11.
• To drive the nail deeper, turn the adjustment knob
clockwise, see figure 15.
4.Reload nails as described in the “Nail Loading” section of
this manual.
5.Reconnect air supply
Know what is behind your work piece.
Do not fire nails into walls or floors
without assuring the area on the opposite side is clear.
A nail could travel through the work piece, striking someone.
Jam Clearing
Disconnect the tool from the air source
before attempting to clear a jammed nail.
Such precautionary safety measures reduce the risk or
unintentional tool operation.
If a nail becomes jammed in the nosepiece, follow these
instructions to remove the jammed nail:
1.Release the trigger.
2.Disconnect the air supply from the tool.
3.Remove nails from the magazine as described in “Nail
Unloading.”
4.Open the nose of the tool by pulling quick release lever
forward. Pull open the nose of the tool to access the nail
jam, see figure 16.
5.Remove the nail, using pliers if necessary.
6.Close the nose of the tool by hooking the spring of the
quick clear lever on the two hooks on the nose. Press the
lever closed, see figure 17.
7.Reinsert nails into the magazine as described in “Nail
Loading”.
8.Reconnect air supply as described in “Connecting Air
Supply”.
NOTE: If the driver blade does not return to its up position,
disconnect air supply and contact a Bosch factory service
center or authorized Bosch service station.
NOTE: If nails continue to jam frequently in the nose piece,
contact BOSCH service center for repair.
Adjustable Exhaust Deflector
This tool has an adjustable exhaust deflector that allows the
exhaust air to be blown away from user or workpiece.
Operation
!
W
ARNING
!
WARNING
FIG. 16
FIG. 17
BM 2610957380 02-09:BM FNS250-16 06-09 6/17/09 8:05 AM Page 11
