5.
Functional Description and Specifications
Disconnect the tool from the air source before making any adjustments, changing accessories or
s
toring the tool. Such precautionary safety measures reduce the risk or unintentional tool operation.
!
WARNING
Specifications
Product Size:
Height - 11 in.
Width - 2.9 in.
Weight: 3.6 lbs.
Normal Operating Pressure: 60 to 120 PSI
Magazine Capacity: 100 Nails
Maintenance: Oiling
Firing Modes: Bump Fire or Sequential Fire
Air Consumption, one shot per second @ 100 psi: 2.6 CFM
Maximum Capacities
Nails: Diameter 16 gage
Length (Range): 1 in. to 2-1/2 in.
Nail Loading & Change Out: Back
Additional Features
Tool-Less No-Mar Tip
Adjustable Exhaust
Deflector
Depth of Drive Adjustment
No-Mar Tip
Housing
Top Cap
Work Contact
Element
Trigger
Magazine
Selectable Firing
Mode Switch
Nail Follower
Air Fitting
(Not Included)
Handle
Quick
Release
Lever
FIG. 1
Bypass Lever
No Mar Tip
Storage
Nail Hold
Back Spring
