13.
No-Mar Pad
T
he No-Mar Pad on the nose of the work contact element
protects the work piece from the work contact element toe
nailing teeth when the work piece contact is compressed
during actuation. The pad can be removed and replaced.
Disconnect the air supply from the tool
and remove nail strips before removing
or replacing no-mar pads. Such precautionary safety
measures reduce the risk or unintentional tool operation.
To remove the pad: Pull the no mar tip towards the back of
the tool following the bend of the wire nose.
To replace the pad. Push the no mar tip on to the tool
inserting the opening of the no mar tip on to the wire nose.
Compressor
A correctly sized compressor is critical for maximum tool
performance. Use the following calculation to determine the
required compressor size.
Air Consumption, one shot per second @ 100 psi: 2.6 CFM
No-Mar Pad
FIG. 18
Accessories
!
WARNING
Compressor size (CFM) =
60
x Shots per minute x Number of tools x 1.2
Air Consumption(CFM)
