Appendix
17
Product specifications
Printer specifications
Paper sizes (print area)
3Appendix
Indicators
Status indicator light (blue/green/red)
Charging indicator light (orange)
Printing
Method
Direct thermal printing with a line thermal print head
Resolution 300 dpi × 300 dpi
Print speed
15 seconds/sheet
(standard text on thermal paper with 7 % cover-
age at an ambient temperature of 74.6 °F / 25 °C)
No. of
pages that
can be
printed
100 or more during continuous printing with a fully
charged battery. Using Bluetooth sleep mode will
affect this figure. (Based on 7% coverage at an
ambient temperature of 74.6 °F / 25 °C) (Stan-
dard paper manufactured by Brother: A7 thermal)
Paper supply
method
Brother paper cassette, automatic paper
feed mechanism
Paper
Brother A7 cut paper (2.9" (74 mm) × 4.1" (105 mm))
Power supply
Compact switching AC adapter for charging,
lithium ion battery (built in) 780 mAh (7.4 V)
Interface
Complies with USB Ver. 1.1 and compliant with Blue-
tooth ver. 1.1 class 2 serial port profile supported
Dimensions
3.9" (100 mm) (W) × 6.3" (160 mm) (not
including projection) (D) × 0.7" (17.5 mm) (H)
Weight
0.66 lbs. (300 g) (including the built-in lithium
ion battery and a paper cassette containing
50 sheets of plain thermal paper)
Normal type
A7 size: 2.9
" (
74 mm) × 4.1
"
(105 mm)
(2.7
"
(69 mm) × 3.9
"
(100 mm))
Label sheets
(four down)
2.9
" (
74 mm) × 1.0
"
(26.25 mm)
(2.7
"
(69 mm) × 0.8
"
(21.25 mm))
Label sheets
(two down)
2.9
" (
74 mm) × 2.1
"
(52.5 mm)
(2.7
"
(69 mm) × 1.9
"
(47.5 mm))
