Operating Instructions and Parts Manual FP260200
www.chpower.com
Replacement Parts List
Ref.
No.
Description
Part Number Qty.
1 Accessory Compartment Insert s 1
2 On / Off Switch FP205129AV 1
3 Shroud s 1
4 Screw n 4
5 Shroud Insert s 1
6 Screw s 4
7 Screw n 2
8 Pump / Motor Assembly FP060000AV 1
9 Motor Cover l 1
10 Motor Cover Isolator l 1
11 Screw k 1
12 Wire Clip FP202823AV 1
13 Screw n 2
14 Exhaust Tube Assembly FP202839AV 1
15 Hose FP209535AV 1
16 Wire (Pressure Switch to
Power Switch) FP209523AV 1
17 Power Cord u 1
18 Wire Clip / Strain Relief u 1
19 Screw k 1
20 Washer with Teeth k 1
21 Terminal -- 1
22 Outlet Gauge FP204013AV t 1
23 Tank Gauge FP204012AV t 1
24 Regulator and Manifold
Assembly FP018800AV t 1
25 ASME Safety Valve V-215100AV 1
26 Check Valve Assembly FP209532AV 1
27 Check Valve -- 1
28 Poppet -- 1
29 Spring -- 1
30 Pressure Switch FP018400AV 1
31 Tank -- 1
32 Drain Valve D-1403 1
33 Screw n t 4
34 Manifold Cover -- 1
35 Screw H 2
36 Pressure Switch Plate H 1
37 Pressure Switch Bracket H 1
38 Rubber Foot
4
39 Washer k 4
40 Rivet -- 4
41 End Cap -- 4
42 Hook FP209521AV 1
43 Rubber Grommet -- 2
44 Gasket t 2
45 Handle Grip -- 1
REPLACEMENT PARTS KITS
s Shroud Kit FP018900AV
n Fastener Kit FP019000AV
l Motor Cover Kit FP018700AV
u Powercord with Strain Relief FP209534AV
t Manifold Assembly Kit FP019100AV
H Pressure Switch Bracket Kit FP019200AV
Rubber Foot Kit FP209522AV
k Standard hardware item - available at your local
hardware store
-- Not Available
