Campbell Hausfeld HL5403 Air Compressor User Manual



HL5403, HL5404
32
Notes
Notas
CALIFORNIA PROPOSITION 65
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
This
product
or its power cord contains lead, a
chemical known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
Have the serial number, model number,
and parts list (with missing parts circled
before calling.)
General Safety
Information
Do not
operate
unit if damaged during shipping,
handling or use. Damage may result in
bursting and cause injury or property
damage.
Do not
run
unattended. Leaving compressor in
AUTO position may allow it to turn on
inadvertently. To prevent this and
possible damage from power surge,
turn to OFF position after each use.
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
© 2008
Description
This oil-lubricated compressor is
designed for do-it-yourselfers with a
variety of home and automotive jobs.
These compressors power spray guns,
impact wrenches and other tools.
Compressed air from this unit will
contain moisture. Install a water filter or
air dryer if application requires dry air.
Safety Guidelines
This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS.
To help recognize this information,
observe the following symbols.
Danger
indicates
an imminently hazardous situation
which, if not avoided, WILL result in
death or serious injury.
Warning
indicates
a potentially hazardous situation
which, if not avoided, COULD result in
death or serious injury.
C
aution
indicates
a potentially hazardous situation
which, if not avoided, MAY result in
minor or moderate injury.
Notice
indicates
important information, that if not
followed, MAY cause damage to
equipment.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may have
occurred during transit. Make sure to
tighten fittings, bolts, etc., before
putting unit into service. In case of
questions, damaged or missing parts,
please call 1-800-543-6400 for customer
assistance.
Operating Instructions and Parts List HL5403, HL5404
IN626400AV 6/08
Breathable Air Warning
This compressor/pump is not
equipped and should not be used
“as is” to supply breathing quality
air. For any application of air for
human consumption, the air
compressor/pump will need to be
fitted with suitable in-line safety
and alarm equipment. This
additional equipment is necessary
to properly filter and purify the air
to meet minimal specifications for
Grade D breathing as described in
Compressed Gas Association
Commodity Specification G 7.1 -
1966, OSHA 29 CFR 1910. 134,
and/or Canadian Standards
Associations (CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is used
for the purpose of breathing air
application and proper in-line
safety and alarm equipment is not
simultaneously used, existing
warranties shall be voided, and the
manufacturer disclaims any liability
whatsoever for any loss, personal
injury or damage.
STOP!
Record the Model No., Serial No. and
date of purchase located on the base
below the pump in the space below.
Model No.____________________
Serial No. ____________________
Date of purchase _________________
Retain these numbers for future
reference.
Oil Lubricated Compressors
DO NOT RETURN THE
PRODUCT TO THE
RETAILER!
See Warranty on page 10 for important information about commercial use of this product.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
