SKU 98544 For technical questions, please call 1-800-444-3353. Page 11
is fully charged, unplug the Charger
from the electrical outlet and remove
the Battery Pack from the Adapter.
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set
up or use of this product.
Work Piece and Work Area Set Up
Designate a work area that is clean 1.
and well-lit. The work area must not
allow access by children or pets to
prevent injury and distraction.
Secure loose work pieces using a 2.
vise or clamps (not included) to pre-
vent movement while working.
There must not be hazardous ob-3.
jects, such as utility lines or foreign
objects, nearby that will present a
hazard while working.
General Operating Instructions
NOTE: For additional information regarding
the parts listed in the following pages,
refer to the Parts List & Assembly
Diagram.
Remove the
Battery Pack (44)
from the tool and set the
Direction Lever (38) to its
center, locked, position before
making any adjustments,
changing accessories, or
storing the tool.
1. In order to use the included screw-
driver bits, you must first attach the
Bit Adapter (62) into the Chuck (2).
With the Chuck pointing away from
you, turn the Chuck counterclock-
wise. Insert the shank of the Bit
Adapter all the way into the Chuck.
Turn the Chuck clockwise to lock the
Bit Adapter in place.
The Chuck accepts up to 3/8” diam-2.
eter bits. Insert the appropriate bit
for your application and tighten the
Chuck firmly. Never insert one of
the included Bits directly into the
Chuck. A smaller gauge than 3/8”
will not be firmly secured and may
result in injury or property dam-
age.
Secure the workpiece in place, using 3.
a vise or clamps (not included).
CAUTION: Never change Torque Set-
ting while drill is still rotating, as
this can damage the Drill/Driver.
Torque Control (6)
Chuck (2)
Direction
Lever (38)
Trigger (61)
Battery Pack
(44)
