PARTS LIST
Part Description Qty.
1 Screw (M6 x 16) 1
2 3/8” Keyless Chuck 1
3 Screw (M2.2 x 12) 4
4 Mounting Plate 1
5 Spring Holder 1
6 Torque Control 1
7 Sleeve 1
8 Torque Spring 1
9 C-Ring 1
10 Washer 1
11 Ball 15
12 Washer 1
13 Clutch Washer 1
14 Ball 16
15 Bushing 1
16 Gear Housing 1
17 Output Shaft 1
18 Ring Gear 1
19 Planet Gear 6
20 Sun Gear 1
21 Washer 1
22 Screw (M3x6) 2
23 Mounting Bracket 1
24 Screw (M2.2x12) 4
25 Motor Pinion 1
26 Motor 1
27 Screw (M2.9x14) 2
28 Housing Cover 1
29 Screw (M2.9x16) 7
30 E-Washer 1
31 Red Wire
PARTS LIST
Part Description Qty.
32 Black Wire 1
33 Speed Switch 1
34 Rivet 2
35 Positive Contact Plate 1
36 Negative Contact Plate 1
37 Control Contact Plate 1
38  1
39 Housing Support 1
40 Screw (M2.9x10) 1
41 Recharging Contact Plate 2
42 Heat Sink 1
43 PCB Supporter 1
44 Battery Pack 1
45 Battery Pack Holder 1
46  1
47  1
48 Screw (M2.2x8) 1
49 Power Pack 1
50 Holder Plate 1
51 Charging Plate 3
52 Screw (M2.2x14 4) 4
53 Power Pack Cover 1
54 Charger Housing 1
55 Spring Plate 1
56 Charger Contact Plate 2
57 Charger 1
58 Charger Stand Support 1
59 Screw (M2.2x14) 4
60 Adapter 1
61 Trigger 1
62 Bit Adapters 1 set
