PAGE 8
Always connect the Female Quick Cou-
pler to the air hose. Never connect the
Female Quick Coupler to the tool.
Never carry the tool by the hose or pull
the hose to move the tool or a com-
pressor. Keep hoses away from heat,
oil, and sharp edges. Replace any
damaged, weak or worn hoses.
Do not use any type of flammable gases
or oxygen as a power source for the tool.
Use filtered, lubricated, regulated com-
pressed air only. Use of compressed gas
instead of compressed air may cause
the tool to explode and cause death or
serious personal injury.
NOTE
For better performance, install a 3/8"
Quick Connector (1/4" NPT threads)
with an inside diameter of .315 (8 mm) on
your Tool and a 3/8" Quick Coupler on
the air hose. A minimum of 3/8" I.D. air
hose with a rated working pressure of
150 PSI or above should be used.
NOTE
Excessive oil will damage o-rings and
seal of tool. If in-line oiler is used,
manual lubrication through the air
inlet is not required on a daily basis.
Regulator
Oiler
Air Flow
Figure 3
The air compressor must be able to maintain
a minimum of 65 PSI when the tool is being
used. An inadequate air supply can cause a
loss of power or inconsistent operation.
Do not use a check valve or any other
fittings which will allow air to remain in
the tool. Serious personal injury or prop-
erty damage could occur.
Use a Pressure Regulator on your
compressor with an operating pressure
of 0-125 PSI. A Pressure Regulator is
required to control the operating pres-
sure of your tool. Refer to the label on
your nailer/stapler for the maximum
P.S.I.
Filter
