G0486/G0487 Wide Belt Sander -59-
Sanding Drum and Platen Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P04865101 BEARING HOUSING 305 PS01 PHLP HD SCR 10-24 X 1/2
102 P05815102 RUBBER ROLLER (G0486) 306 P05815306 GRAPHITE PRESSURE PLATE (G0486)
102 P04875102 RUBBER ROLLER (G0487) 306 P04875306 GRAPHITE PRESSURE PLATE (G0487)
103 P04865103 FASTENING TUBE 307 P04865307 GRAPHITE BRACKET BASE
104 P05275104 CYL. CARTRIDGE BEARING UCC206 308 P04865308 GRAPHITE BRACKET SHAFT (G0486)
105 P04865105 PULLEY 308 P04875308 GRAPHITE BRACKET SHAFT (G0487)
106 PSB11 CAP SCREW 5/16-18 X 1-1/4 309 P04865309 LOCK COLLAR
107 PK11 KEY 5/16 X 5/16 X 1-3/16 310 PSS03 SET SCREW 1/4-20 X 3/8
108 PLW01 LOCK WASHER 5/16 311 PK110 KEY 1/4 X 1/4 X 1
109 P6205 BALL BEARING 6205ZZ 312 P04865312 COMPRESSION SPRING
110 PLW07 LOCK WASHER 1/2 313 P04865313 HOUSING
111 PSB76 CAP SCREW 1/2-12 X 1-1/2 314 P04865314 GRAPHITE BRACKET SHAFT
112 PSB04 CAP SCREW 1/4-20 X 1/2 315 PSB16 CAP SCREW 3/8-16 X 3/4
113 P04865113 BEARING CAP 316 PW02 FLAT WASHER 3/8
114 P04865114 GREASE FITTING W/CAP 317 PW02 FLAT WASHER 3/8
115 P04865115 GREASE FITTING W/CAP 318 P04865318 HANDLE
116 P04865116 PLUG 319 PSS08 SET SCREW 5/16-18 X 1/2
117 P04865117 PULLEY COVER 320 P04865320 ADJUSTMENT RING
118 PS04 PHLP HD SCR 1/4-20 X 1/2 321 PB03 HEX BOLT 5/16-18 X 1
119 P04865119 SPANNER NUT 322 PW07 FLAT WASHER 5/16
201 P04865201 BEARING HOUSING 323 P04865323 HANDLE
202 P05815202 STEEL ROLLER (G0486) 325 P04865325 GRAPHITE BRACKET ADJ. ASSEMBLY
202 P04875202 STEEL ROLLER (G0487) 401 P04865401 BEARING HOUSING
203 P04865203 SPECIAL CAP SCREW M6-.75 X 6 402 P05815402 RUBBER ROLLER (G0486)
204 P05275104 CYL. CARTRIDGE BEARING UCC205 402 P04875402 RUBBER ROLLER (G0487)
205 P04865205 HANDLE 403 P04865403 FASTENING TUBE
206 P04865206 SPECIAL SCREW 404 P05275104 CYL.CARTRIDGE BEARING UCC206
211 P04865211 BEARING BRACKET PAD 405 P04865405 PULLEY
301 P05815301 44" GRAPHITE BRACKET MALE (G0486) 406 PSB11 CAP SCREW 5/16-18 X 1-1/4
301 P04875301 52" GRAPHITE BRACKET MALE (G0487) 407 P04865407 BEARING HOUSING
302 P05815302 44" GRAPHITE BRACKET FML (G0486) 408 P04865408 BEARING BRACKET PAD
302 P04875302 52" GRAPHITE BRACKET FML (G0487) 409 P6206 BEARING 6206ZZ
303 P05810004 44" FELT PLATEN PAD (G0486) 410 P04865410 SPANNER NUT
303 P04875303 52" FELT PLATEN PAD (G0487) 411 P04865411 BEARING CAP
304 P05810005 GRAPHITE 44" X 3.54" (G0486) 417 P04865417 PULLEY COVER
304 P04875304 GRAPHITE 52" X 3.54" (G0487)
