OPERATION
Step 1:Perform all adjustments as required (see ADJUSTMENTS section) depending upon
material thickness and whether you are engaging in straight rolls or cones.
Step 2:Insert material’s edge between SHAFT I (#17) and SHAFT II (#18). See Figure 3.
Step 3:Turn HANDLE (#19) to process material.
Step 4:If you are only performing partial rolls and need to remove the material, slide out the
SHAFT BUSHING (#11) and pull Shaft I forward. See Figure 4.
Page 6 -- SKU 36698
Shaft Bushing (#11)
