SKU 43753 For technical questions, please call 1-800-444-3353. Page 2
Specications
Capacity 7” Coil Spring Diameter
Maximum Opening 8”
Hardware Tensile 113-128 PSI, Minimum
Lead Screw 11-3/8” L x 5/8” Diameter
Lead Screw Torque 15 ft-lb Minimum
Support Arms 3/8” Steel Flat Stock
Support Arms Length 15-1/4”
Compressor Type Mac-Pherson Struts Only
Tool Weight 17-1/4 lb.
Save This Manual
You will need the manual for the safety warnings and precautions, assembly
instructions, operating and maintenance procedures, parts list and diagram. Keep your
invoice with this manual. Write the invoice number on the inside of the front cover.
Keep the manual and invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this product!
Avoid working alone1. . If an accident happens, an assistant can bring help.
Keep work area clean2. . Cluttered areas invite injuries.
Observe work area conditions3. . Don’t expose to rain. Keep work area well lit.
Keep children away4. . Children must never be allowed in the work area. Do not
let them handle machines, tools, or extension cords.
Store idle equipment5. . When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.
Dress properly6. . Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically nonconductive clothes and nonskid footwear
are recommended when working. Wear restrictive hair covering to contain long
hair.
Use eye and ear protection7. . Always wear ANSI approved impact safety goggles.
Do not overreach8. . Keep proper footing and balance at all times. Do not reach
over or across electrical cables or frames.
Use the right tool for the job9. . Do not attempt to force a small tool or attachment
to do the work of a larger industrial tool. There are certain applications for which
this tool was designed. Do not modify this tool and do not use this tool for a pur-
pose for which it was not intended.
