Page 13SKU 44846
Pulley and Spindle Assembly Parts List
Item # Description
A1 V-belt, M58
A2 Pulley Nut
A3 Spindle Pulley
A4 Insert Pulley
A5 Retaining Ring
A6 Locking Ring
A7 Washer
A8 Ball Bearing, 60203
A9 Washer, Rubber
A10 Quill Tube
A11 Chuck Key
A12 Chuck
A13 Arbor
Item # Description
A14 Drift Key
A15 Spindle
A16 Ball Bearing, 60204
A17 Knob
A18 Screw, M5x12
A19 Screw, M5x12
A20 Clamp Cord
A21 Screw, M6x12
A23 Motor Pulley
A24 Screw, M6x10
A25 Belt Guard
A26 Form Washer
Pulley and Spindle Assembly Drawing
When ordering a part from this drawing, add an “A” prefix to the part number.
